Spezifikationen

Gesamtleistung:
240 W RMS x 1 @ 4 ohm (12.5V);
400 W RMS x 1 @ 2 ohm (12.5V)

Klirrfaktor:
<0.08% @ 4 ohm (20 Hz -20 kHz)

Rauschabstand:
>90 dB referred to rated power (A-weighted, 20 Hz – 20 kHz noise bandwidth)

Frequenzbereich:
10 Hz – 250 Hz (+0, -1dB)

Dämpfungsfaktor
>500 @ 4 ohm / 50 Hz
>250 @ 2 ohm / 50 Hz

Eingangsspannung
200mV – 8V RMS

Abmaße :
30cm x 23,5 cm x 6,0 cm

Features:
High-Damping Class D Circuit with discrete control circuitry (U.S. Patent #6,441,685)
Differential-Balanced Input Topology:
RCA jack inputs (low-level) and multi-pin jack (high-level)
On-board Crossover:
Fully-variable (40-200 Hz), selectable slope Low-Pass (12 or 24 dB / octave)

Preamp Output:
Pass-through type.
Bass EQ :
+6db fixed frequency, fixed 'Q' (defeatable) with port for optional remote bass control (RBC-1).
Dual mono speaker output connections:
accept up to 8 AWG wire
+12V and Ground connections:
accept up to 4 AWG wire
